Description
Our 10mm 12mm 2 Pin Push Button Switch is a high-quality electrical component ideal for a wide range of applications. As a factory-direct supplier and wholesaler, we offer competitive prices and reliable products. This switch features a maximum rating of 1A 250V AC, ensuring stable performance under various conditions. With a contact resistance of ≤50mΩ and insulation resistance of ≥100mΩ, it guarantees efficient and safe operation. The switch is designed to withstand an operating temperature range of -5℃ to +55℃ and has an IP40 protection level, making it suitable for both indoor and outdoor use. Our product is available in multiple cap colors including Red, Yellow, Green, Black, White, Blue, Gray, and Orange, allowing for customization to match your design needs. Additionally, it boasts an impressive electronic life of 10,000 cycles, ensuring long-lasting durability. Certified by CQC and CE, our switch meets international quality standards. Choose our push button switch for its superior quality, competitive pricing, and reliable performance. Contact us today for wholesale inquiries!
| Max. Rating Current & Voltage |
1A 250V AC |
| Contact Resistance | ≤50mΩ kinetic switch |
| Insulation Resistance | 100MΩ push button switch |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | 10,000 micro switch button |
| Certification |
CQC |
| Operating temperature | -5℃~+55℃ |
| IP code | IP40 |
Key Features
Our 10mm 12mm 2 Pin Push Button Switch stands out with its robust design, high-quality materials, and reliable performance. It is perfect for applications requiring on/off control with stability and durability.
Why Choose Us?
As a factory-direct supplier and wholesaler, we offer competitive pricing without compromising on quality. Our switches are certified by CQC and CE, ensuring they meet international standards.
Applications
This push button switch is widely used in electrical equipment, industrial control systems, and home appliances. Its versatility and reliability make it a preferred choice for various industries.
