Description
Introducing our high-quality 10mm 1NO1NC LED Push Button Switch, a must-have for any electronic project or industrial application. As a factory direct supplier and wholesaler, we offer competitive prices and top-notch quality. This switch features a momentary action, making it perfect for applications requiring temporary contact. With a maximum rating of 3A/250V AC, it can handle a wide range of electrical loads. The built-in LED indicator, available in multiple colors (red, green, yellow, blue, orange, white, black, gray), provides visual feedback, enhancing user experience. Our switch is designed with durability in mind, boasting a contact resistance of ≤50mΩ, insulation resistance of ≥1000 MΩ, and a dielectric strength of 1500V. It offers an impressive electronic life of 50,000 cycles and a mechanical life of 200,000 cycles, ensuring long-lasting performance. The operating temperature range of -5°C to +75°C makes it suitable for various environments. With an IP40 protection level, it’s resistant to dust and water splashes. Choose from round, mushroom, square, or rectangular pushbutton heads to fit your design needs. Panel cutout size is 10mm, and the indicator voltage options include 2V, 6V, 12V, 24V, 110V, and 220V. Certified by CQC and CE, our switch meets international safety standards. We provide excellent after-sales service, ensuring your satisfaction. Order now and take advantage of our wholesale pricing!
| Max.Rating Current & Voltage(Resistive Load) |
3A/250V AC |
| Contact Resistance |
≤50mΩ |
| Insulation Resistance |
≥1000 MΩ |
| Dielectric Strength |
1500V |
| Electronic Life(cycles) |
50000 |
| Mechanical Life(cycles) |
200000 |
| Operating temperature |
-5°c~+75°c |
| IP code |
IP40 |
Why Choose Our 10mm 1NO1NC LED Push Button Switch?
Our 10mm 1NO1NC LED Push Button Switch stands out for its durability, versatility, and user-friendly design. The momentary action ensures precise control, while the LED indicator provides clear visual feedback. With a wide range of voltage and current ratings, it's suitable for various applications.
What Makes Our Switch Different?
Unlike many competitors, our switch is factory-direct, ensuring quality control and competitive pricing. The multiple color options for the LED indicator allow for customization to match your design. Additionally, the long electronic and mechanical life guarantees reliability and reduces maintenance costs.
How Can I Benefit from Buying Wholesale?
As a wholesaler, we offer significant discounts on bulk purchases. This is ideal for businesses or individuals looking to stock up on switches for multiple projects or to resell. Our factory-direct pricing means you get the best value for your money, without compromising on quality.
