Description
Introducing our premium 12mm 2pin Push Button Switch, a must-have for refrigerator doors and various electrical applications. As a factory-direct supplier, we offer wholesale prices on this high-quality, plastic white switch. It features a normal close (NC) function, with a maximum current of 1A and a voltage rating of 250V AC. Our switch stands out with its IP40 protection level, ensuring durability and safety. With a mechanical life of 50,000 times and an electrical life of 100,000 times, it guarantees long-lasting performance. The switch is designed to fit a 12mm mounting hole and accommodates panel thicknesses from 0.4-0.6mm, 0.8-2.4mm, to 1.4-1.6mm. Choose our switch for its reliability, affordability, and exceptional after-sales service.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
KA5-15-NC-WW
|
|
Protection Level
|
IP40
|
|
Max. Current
|
1A
|
|
Max. Voltage
|
250V AC
|
|
Contact Resistance
|
50mΩ Max.
|
|
Insulation Resistance
|
100MΩ Min.
|
|
Dielectric Strength
|
1500V
|
|
Mechanical Life
|
50000 Times
|
|
Electrical Life
|
100000 Times
|
|
Operating temperature
|
-25℃~+55℃
|
|
Protection Class
|
IP40
|
|
Mounting Hole Size
|
12mm
|
|
Function
|
NC,NO
|
|
Panel Thickness
|
0.4-0.6, 0.8-2.4, 1.4-1.6
|
Why Choose Our 12mm 2pin Push Button Switch?
Our 12mm 2pin Push Button Switch is designed for durability and performance, making it an ideal choice for refrigerator doors and various electrical applications. With a normal close (NC) function, it ensures reliable operation and safety.
What Are the Key Features of Our Switch?
Key features include a maximum current of 1A, a voltage rating of 250V AC, and an IP40 protection level. It also boasts a long mechanical life of 50,000 times and an electrical life of 100,000 times, ensuring long-lasting reliability.
Why Buy from Us as a Factory Supplier?
As a factory supplier, we offer wholesale prices and exceptional after-sales service. Our switch is designed to fit a 12mm mounting hole and accommodates various panel thicknesses, making it versatile and easy to install. Choose us for quality, affordability, and reliability.
