12mm Momentary Push Button – Wholesale Factory Supplier

Description

Introducing our high-quality 12mm Momentary Push Button, designed specifically for water dispensers. As a leading factory and supplier, we offer wholesale pricing on this normally open push button switch, perfect for a variety of applications. With a maximum rating of 1A 250V AC, this button ensures reliable performance in demanding environments. Our product stands out with its exceptional durability, boasting a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles. It features low contact resistance (≤50mΩ) and high insulation resistance (≥100mΩ), ensuring safety and efficiency. The button is available in multiple colors including white, black, blue, and grey, allowing you to choose the one that best matches your device. Certified with CQC and CE, it meets international quality standards. Operating within a temperature range of -25℃ to +55℃ and with an IP40 protection level, this push button is suitable for various industrial and commercial uses. As a factory-direct supplier, we offer competitive pricing and excellent customer service. Don’t miss out on this opportunity to enhance your water dispenser with our reliable push button switch.
Max. Rating Current & Voltage

1A 250V AC

Contact Resistance ≤50MΩ
Insulation Resistance ≥100MΩ
Dielectric Resistance 1,500V
Electronic life(cycles) 10,000
Mechanical life(cycles) 50,000
Certification

CQC , CE

Operating temperature -25℃~+55℃
IP code IP40

Electronic component for cross-border e-commerceElectronic device on cross-border e-commerce siteElectronic product for cross-border e-commerceElectronic gadget on cross-border e-commerce


Why Choose Our 12mm Momentary Push Button?

Our 12mm Momentary Push Button is designed for water dispensers and other industrial applications, offering reliable performance and durability. With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, it ensures long-lasting use. The button's normally open configuration and low contact resistance make it ideal for precise control.

What Are the Key Features?

Key features include a maximum rating of 1A 250V AC, high insulation resistance (≥100mΩ), and a wide operating temperature range (-25℃ to +55℃). It is available in multiple colors and certified with CQC and CE, ensuring quality and safety.

How Does It Benefit Your Business?

As a factory-direct supplier, we offer wholesale pricing, making it cost-effective for your business. The button's high durability and reliability reduce maintenance costs and downtime, enhancing your product's overall value and customer satisfaction.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

1A

Max. Voltage

250V

Place of Origin

Shanghai, China

Brand Name

Shangkai(SK)

Model Number

KA5

LED

Other

Whether the smart

NO

Switch Combination

1NO

Color

White black blue grey

Mechanical life

50000cycles

Electronic life

10000cycles

Operating temperature

-25℃~+55℃

Contact Resistance

≤50mΩ

Insulation Resistance

≥100mΩ

Dielectric Resistance

1,500V

Certification

CQC CE

Protection Level

IP40
