Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11N-CA1A-B-R-01-12D
|
|
Max. Current
|
6A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST with led light
|
|
Dimension Code
|
A1 (21.7x15x15.8 , 19.1x13x13)
|
|
Contact Piece Code
|
A (8 length, 4.8×0.8 standard)
|
|
Lamp voltage
|
12V DC
|
|
Function
|
On Off Illuminated
|
Why Choose Our 12V LED Rocker Switch?
Our 12V LED Rocker Switch stands out with its robust construction, reliable performance, and long lifespan. With a 6A current rating and 250VAC voltage capacity, it's perfect for a wide range of electrical applications. The illuminated design ensures easy visibility in low-light conditions, making it ideal for industrial and home use.
What Are the Key Features?
Key features include a 50,000-cycle mechanical life, 10,000-cycle electronic life, and compliance with multiple safety certifications. The switch also offers low contact resistance and high insulation resistance, ensuring safe and efficient operation.
Why Buy from Us?
As a factory-direct supplier and wholesaler, we offer unbeatable quality and value. Our products are rigorously tested to meet international standards, and we provide excellent customer service and after-sales support. Choose us for reliable, high-quality electrical components.
