Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
KA6-11-BAA-RB
|
|
Protection Level
|
IP40
|
|
Max. Current
|
3A
|
|
Max. Voltage
|
250V AC
|
|
Contact Resistance
|
50mΩ Max.
|
|
Insulation Resistance
|
100MΩ Min.
|
|
Dielectric Strength
|
1500V
|
|
Electrical Life
|
10000 Times
|
|
Operating temperature
|
-25℃~+85℃
|
|
Mounting Hole Size
|
14mm
|
Why Choose Our 14mm Push Button Switch?
Our 14mm Push Button Switch stands out for its durability, reliability, and versatility. Crafted from high-quality plastic, it offers excellent protection against dust with an IP40 rating. With a maximum current of 3A and voltage of 250V AC, it's suitable for a wide range of applications, including small instruments and water dispensers. Its mechanical operation ensures smooth and reliable switching, while a high electrical life of 10000 times guarantees long-term performance.
What Are the Key Features of Our Switch?
Key features include a compact 14mm size, low contact resistance (50mΩ Max.), and high insulation resistance (100MΩ Min.). It also boasts a dielectric strength of 1500V, ensuring safety in high-voltage environments. The switch operates within a wide temperature range (-25℃ to +85℃), making it suitable for various climates and conditions.
Why Buy from Us as a Factory Supplier?
As a factory supplier, we offer competitive wholesale prices and direct access to our high-quality products. We pride ourselves on excellent customer service and fast shipping, ensuring you receive your order promptly and hassle-free. Choose us for reliable, durable, and cost-effective push button switches that meet your needs and exceed your expectations.
