Description
**Key Specifications**:
– Max. Current: 3A
– Max. Voltage: 250V AC
– Mechanical Life: 50,000 cycles
– Electronic Life: 10,000 cycles
– Operating Temperature: -25℃ to +85℃
– Dielectric Strength: 1500V
– Contact Resistance: ≤50MΩ
– Insulation Resistance: ≥100MΩ
**Advantages**:
– Waterproof design with IP65 rating ensures reliability in wet conditions.
– Durable metal/plastic construction guarantees long-lasting performance.
– Momentary or latching action options provide flexibility for different applications.
– Wide color selection to match your design requirements.
**After-Sales Service**:
We stand behind our products with excellent after-sales service. Should you have any questions or concerns, our dedicated support team is here to assist you.
Choose our factory-direct push button switch for unbeatable quality, value, and service.
|
contact resistance
|
≤50MΩ
|
electronic life（cycles）
|
10000
|
|
insulation resistance
|
≥100MΩ
|
mechanical life（cycles）
|
50000
|
|
dielectric strength
|
1500V
|
operating temperature
|
25T85
|
|
IP code
|
IP65
|
max.rating current & voltage
|
3A 250V AC
|
Why Choose Our 14mm Waterproof Push Button Switch?
Our 14mm Waterproof Push Button Switch stands out for its durability, versatility, and affordability. As a factory supplier, we offer wholesale pricing without compromising on quality. The IP65 rating ensures it can withstand wet conditions, making it ideal for outdoor or industrial use.
Key Features and Benefits
With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, this switch is built to last. The momentary or latching action options provide flexibility for various applications. Additionally, the wide color selection allows you to match it with your design requirements.
After-Sales Support and Warranty
We are committed to providing excellent after-sales service. Should you encounter any issues, our dedicated support team is ready to assist you. Plus, our products come with a warranty to give you peace of mind.
