Description
Introducing our high-quality 14mm SPST 1NO self-latched plastic waterproof black push button switch, a reliable solution for various applications. As a direct factory supplier and wholesaler, we offer competitive prices and excellent quality. This switch is crafted from durable PA66 material, ensuring longevity and stability. It features a latching push button action, making it ideal for electric, home appliance, and industrial control applications. With a max. rating current of 3A and a max. rating voltage of 250V AC, it can handle demanding electrical loads. The switch has a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, guaranteeing reliable performance over time. Its IP65 rating ensures protection against dust and water, making it suitable for harsh environments. The operating temperature range is from -25℃ to +85℃, providing versatility in different conditions. Additionally, the switch comes with CQC and CE certifications, ensuring compliance with international standards. Choose our factory-direct push button switch for superior quality, competitive pricing, and reliable service.
|
contact resistance
|
≤50MΩ
|
mechanical life（cycles）
|
50000
|
|
insulation resistance
|
≥100MΩ
|
electronic life（cycles）
|
10000
|
|
dielectric strength
|
1500V
|
operating temperature
|
-25℃ to +85℃
|
|
IP code
|
IP65
|
max.rating current & voltage
|
3A 250V AC
|
Key Features
Our 14mm waterproof push button switch stands out with its durable PA66 construction, self-latched mechanism, and IP65 rating, ensuring reliability in various applications.
Applications
Ideal for electric, home appliance, and industrial control uses, this switch excels in environments requiring waterproof and dustproof solutions.
Why Choose Us
As a factory supplier and wholesaler, we offer competitive pricing, superior quality, and reliable service, making us the preferred choice for your push button switch needs.
