Description
Product Specifications:
- Max. Rating Current & Voltage: 16A 250V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100mΩ
- Dielectric Strength: 1500V
- Electronic Life: 50,000 cycles
- Mechanical Life: 100,000 cycles
- Operating Temperature: T125
- IP Level: IP40
- Certifications: CQC ENEC17
Material Composition:
- Contact Leg & Terminals: Brass T=0.8mm
- Contact: Silver alloy
- Case & Gear: PA66
Advantages:
- Durable construction with high-quality materials.
- Long electronic and mechanical life for reliable performance.
- Certified for safety and quality.
- Factory-direct wholesale pricing.
After-Sales Service: We offer comprehensive after-sales support, ensuring your satisfaction with our product.
|
Max. Rating Current & Voltage(Resistive Load) |
6A 250V AC |
|
Contact Resistance |
≤50mΩ |
|
Insulation Resistance |
≥100mΩ |
|
Dielectric Strength |
1500V |
|
Electronic Life(cycles) |
10000cycles |
|
Operating temperature |
T125 |
|
certifications |
CQC ENEC17 |
|
Contact leg |
Brass T=0.8mm |
|
Contact |
Silver alloy |
|
Terminals |
Brass T=0.8mm |
|
Case |
PA66 |
|
Gear |
PA66 |
Why Choose Our Rotary Switch?
Our 16A 250V AC Rotary Switch is designed for durability and reliability, making it perfect for home appliances like ovens and cookers. With a long electronic and mechanical life, it ensures consistent performance over time.
Key Features
The switch is made with high-quality materials, including brass contact legs and terminals, silver alloy contacts, and PA66 case and gear. It is certified for safety and quality, giving you peace of mind.
Factory-Direct Wholesale Pricing
As a factory and supplier, we offer wholesale prices directly to you, eliminating the middleman and saving you money. Choose us for your rotary switch needs and experience the difference in quality and value.
