Description
Introducing our high-quality 16A 250V Self-Lock Push Button Switch, ideal for sewing machines and various industrial applications. As a factory direct supplier, we offer wholesale pricing and ensure top-notch quality. This switch features a robust plastic construction, square head design, and pin terminals for secure connections. With a mechanical life of 50,000 cycles and an electrical life of 10,000 cycles, it guarantees durability and reliability. The switch is rated at 16A 250VAC, with a contact resistance ≤50mΩ and insulation resistance ≥100MΩ, ensuring optimal performance. Its IP40 rating provides protection against dust and limited water ingress. Perfect for electric, home appliance, and industrial control applications, this switch stands out with its latching mechanism and compact size (13.4*20mm). Choose us for factory-direct pricing, reliable supply, and exceptional customer service.
|
contact resistance
|
≤50MΩ
|
electronic life
|
10000
|
|
insulation resistance
|
≥100MΩ
|
operating temperature
|
25T55
|
|
dielectric strength
|
1500V
|
IP code
|
IP40
|
Why Choose Our Self-Lock Push Button Switch?
Our Self-Lock Push Button Switch is designed for durability and reliability, with a mechanical life of 50,000 cycles and an electrical life of 10,000 cycles. It's perfect for sewing machines, industrial control, and home appliances, ensuring smooth operation and longevity.
What Are the Key Features?
Key features include a 16A 250VAC rating, compact size (13.4*20mm), and IP40 protection. The switch also has a latching mechanism for easy operation and a plastic construction for added durability.
Why Buy from Us?
As a factory direct supplier, we offer competitive wholesale pricing and ensure top-notch quality. Our switches are rigorously tested to meet industry standards, and we provide excellent customer service to support your needs.
