Factory Wholesale 16A 250VAC Rocker Switch | Reliable Supplier

Description

Introducing our high-quality 16A 250VAC 3-Pin SPDT Rocker Switch, available for wholesale directly from our factory. As a leading supplier, we ensure each switch meets stringent quality standards. This rocker switch is perfect for a variety of applications, offering a maximum current rating of 16A and a voltage rating of 250VAC. With a contact resistance of 50mΩ and insulation resistance of 1000MΩ, it guarantees reliable performance. Our switch features a durable black housing and a green rocker, providing a clear visual indication. It supports SPDT (Single Pole Double Throw) configuration with 3 pins, and we also offer customizable pin numbers (2, 3, 4, 6) to suit your specific needs. The switch has an electronic life of 10,000 cycles and a mechanical life of 50,000 cycles, ensuring longevity. Certified with CQC, CE, UL, CB, and ENEC, it adheres to international safety standards. Our factory, equipped with advanced machinery and over 60 senior engineers, ensures efficient production and strict quality control. We offer competitive pricing for bulk orders and excellent after-sales service. Choose us as your trusted supplier for all your rocker switch needs.
max.rating cnrrent 16A dielectrice resistance 1500V
max.rating voltage 250V electronic life 10000cycles
contact resistance 50mΩ operating temperature T55,T85,T125
insulation resistance 1000mΩ certifications CQC,CE,UL,CB,ENEC
housing color black(selective) button color green(selective)
PIN number 3 (selective2,3,4,6) circuit SP-DT

Electronic component product imageElectronic device product image


Why Choose Our Rocker Switch?

Our 16A 250VAC 3-Pin SPDT Rocker Switch stands out due to its high current and voltage ratings, ensuring reliable performance in demanding applications. With a durable black housing and green rocker, it offers a clear visual indication and long-lasting durability. As a factory wholesale supplier, we provide competitive pricing and excellent after-sales service.

What Are the Key Features?

Key features include SPDT functionality, customizable pin numbers, a long electronic life of 10,000 cycles, and a high mechanical life of 50,000 cycles. It also adheres to international safety standards with certifications such as CQC, CE, UL, CB, and ENEC.

How Does It Benefit You?

Choosing our rocker switch means benefiting from a product that is designed for reliability, durability, and safety. Our factory's advanced machinery and strict quality control ensure that each switch meets the highest standards. Additionally, our competitive pricing and excellent after-sales service make us the ideal choice for all your rocker switch needs.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A

Max. Voltage

250VAC

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

KCD1-12-CF2B-B-G

Whether the smart

NO

Mechanical Life

50000 Cycles

Product name

Rocker Switch 3 Pin SPDT ON-ON 16A 250VAC Black Green Rocker Switch

Contact resistance

50m Max

Insulation resistance

1000M Min

Dielectric strength

1500VAC 1 Minute

Electronic life

10000 cycles

Panel cutout

F2: 29*13.5mm

Terminal

B: 6.3*0.8mm

Circuit

SPDT on-on 3 pin rocker switch

Color

Black Housing Green Rocker
