Wholesale DPDT Rocker Switch Supplier | 16A 250VAC

Description

Introducing our premium DPDT (Double Pole Double Throw) 6-pin rocker switch, designed for appliances and ideal for wholesale purchases from a trusted supplier and factory. With a maximum current rating of 16A and a voltage rating of 250V AC, this switch is built to handle demanding applications. It features a distinctive red and green double rocker design, making it easy to identify the on/off states. Certified with CE, UL, and CQC, it ensures safety and reliability. Our switch boasts a mechanical life of 50,000-100,000 cycles and an electronic life of 10,000 cycles, outperforming many competitors. With a contact resistance of ≤50mΩ and insulation resistance of ≥1000MΩ, it guarantees efficient and safe operation. The dielectric strength of 1500V AC for 1 minute further enhances its durability. Available in black housing with red and green rockers, it adds a touch of style to your appliances. As a direct factory supplier, we offer competitive pricing and excellent after-sales service. Choose our rocker switch for quality, reliability, and value.
Contact Resistance
≤50mΩ
Insulation Resistance
≥1000MΩ
Dielectric Strength
1500VAC,min

Electronic component device for cross-border e-commerce


Why Choose Our Rocker Switch?

Our DPDT rocker switch is designed for appliances, offering a robust 16A 250VAC rating, ensuring it can handle high-power applications with ease. Its distinctive red and green double rocker design makes it user-friendly, allowing for quick identification of the on/off states.

What Makes Our Switch Stand Out?

With a mechanical life of 50,000-100,000 cycles and an electronic life of 10,000 cycles, our switch outlasts many competitors. Certified with CE, UL, and CQC, it guarantees safety and reliability. The low contact resistance and high insulation resistance ensure efficient and safe operation, while the 1500V AC dielectric strength for 1 minute adds an extra layer of durability.

Why Buy From Us?

As a direct factory supplier, we offer competitive pricing and excellent after-sales service. Our switches are available in bulk, making them ideal for wholesale purchases. Choose our rocker switch for quality, reliability, and unbeatable value.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A

Max. Voltage

250V AC

Place of Origin

Shanghai, China

Brand Name

SK(Shangkai)

Model Number

KCD1-22-CB1A-B-RG(110201-059)

Whether the smart

NO

Mechanical Life

50,000-100,000 cycles

Name

Rocker Switch On Off

Certificate

CE,UL,CQC

Color

black houing, red rocker and green rocker

Circuit Description

DPDT 6 pin rocker switch

Contact Resistance

≤50mΩ

Insulation Resistance

≥1000MΩ

Dielectric Strength

1500V AC , 1min

Max.Rating Current & Voltage

16A 250V AC

Electronic Life(cycles)

10,000 cycles

Certification

CQC CE UL CB ENEC ROHS
