Description
|
item
|
value
|
|
Certification
|
CQC CE ROHS
|
|
Model Number
|
KCD1-11-CF2C-B-B-01
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250VAC
|
|
Mechanical Life
|
100,000 cycles
|
|
Electronic Life
|
10,000 cycles
|
|
Dielectric Strength
|
1,500VAC,1min
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1,000MΩ
|
|
Operating Temperature
|
T85
|
|
Circuit
|
SPST ON-OFF 2Pin
|
|
Panel cutout
|
28×11 mm
|
|
Terminal
|
6.3×0.8 mm standard
|
|
Color
|
Black housing, black actuator
|
|
Marking
|
white I O
|
|
Material
|
PA66
|
Why Choose Our 16A 250VAC Rocker Switch?
Our 16A 250VAC Rocker Switch stands out due to its high durability, with a mechanical life of 100,000 cycles and an electronic life of 10,000 cycles. It is certified with CQC, CE, and ROHS, ensuring safety and reliability. The switch is made from high-quality PA66 material, offering superior resistance to wear and tear. With a dielectric strength of 1,500VAC for 1 minute and low contact resistance, it guarantees optimal performance in various applications.
What Are the Key Features of Our Rocker Switch?
Our rocker switch features a SPST ON-OFF 2Pin circuit, making it easy to use and install. It has a sleek black housing with a black actuator and white I O marking, enhancing its visual appeal. The switch is designed to fit most standard applications with a 28x11 mm panel cutout and a 6.3x0.8 mm standard terminal. Additionally, it can withstand harsh environments with an operating temperature of T85.
How Can Our Rocker Switch Benefit Your Business?
As a factory direct supplier and wholesaler, we offer our 16A 250VAC Rocker Switch at competitive prices, allowing you to save on costs without compromising on quality. Our switch is ideal for use in appliances, industrial equipment, and home automation systems, providing reliable power supply and control. By choosing our product, you can ensure the satisfaction of your customers and enhance the reputation of your business.
