Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(Shangkai), yongxing
|
|
Model Number
|
YB320-500M-2P
|
|
Type
|
Screw Terminal
|
|
Rated voltage
|
300V
|
|
Rated Current
|
16A
|
|
Contact Resistance
|
20mΩ
|
|
Insulation Resistance
|
>5000MΩ DC500V
|
|
Withstand Voltage
|
AC2000V/Min
|
|
Wire range
|
24-12AWG 2.5mm(quadratic)
|
|
Strip Length
|
6-7mm
|
|
Operating Temperature
|
-40℃~+150℃
|
|
Screw
|
M2.5steel Zinc plated
|
|
Contact
|
Brass,Tin plated
|
High Conductivity and Durability
Our Screw Terminal Blocks are crafted with M2.5 steel screws, zinc-plated for enhanced durability, and brass contacts, tin-plated to ensure optimal conductivity. This combination guarantees reliable electrical connections even under demanding conditions.
Wide Temperature Range and Easy Installation
With an operating temperature range from -40℃ to +150℃, our terminal blocks are suitable for a variety of environments. The 6-7mm strip length and 24-12AWG wire range make installation straightforward, accommodating a wide range of wire sizes.
Factory-Direct Pricing and Superior Quality
As a direct factory supplier and wholesaler, we offer competitive pricing without compromising on quality. Choose us for factory-direct pricing, superior quality, and reliable after-sales service, ensuring your electrical connection needs are met with precision and reliability.
