16A 4PIN Rectangle Rocker Switch | Wholesale Factory Supplier

Category: Tags: , , ,
200 - 1,999  pieces
$0.34

2,000 - 4,999  pieces
$0.31

>= 5,000  pieces
$0.28
0 reviews

16A 4PIN Rocker Switch | Wholesale Supplier

Description

Our 16A 4PIN Rectangle Rocker Switch is a high-quality, durable switch designed for a wide range of applications. Made from robust PA66 plastic, this switch ensures longevity and reliability. With a maximum voltage of 250V and a mechanical life of 100,000 times, it outperforms many competitors in the market. The switch is available in multiple colors including Red, Yellow, Green, Blue, and White, allowing for customization to fit your needs. It is suitable for use in cars, industrial equipment, marine applications, buses, and various electric equipment. As a factory direct supplier, we offer wholesale pricing and ensure the highest quality standards with certifications such as CQC, CE, UL, and ENEC. Our switch boasts an insulation resistance of ≥1000MΩ, a dielectric strength of 1500V AC for 1 minute, and operates efficiently within temperature ranges of T55, T85, and T125. With an IP40 rating, it provides adequate protection against dust and water ingress. Choose our switch for its superior performance, reliability, and cost-effectiveness.
contact resistance
≤50MΩ
electronic life（cycles）
10000
insulation resistance
≥1000MΩ
operating temperature
T55 T85 T125
dielectric strength
1500V AC 1min
IP code
IP40

Electronic component for cross-border e-commerce


Why Choose Our 16A 4PIN Rectangle Rocker Switch?

Our switch stands out for its durability, high current rating, and wide operating temperature range. Made from PA66 plastic, it ensures long-lasting performance even in harsh environments. With a mechanical life of 100,000 times, it offers reliability that few competitors can match.

What Are the Key Features of Our Switch?

Key features include a 16A current rating, 250V voltage capacity, 4PIN configuration, and an IP40 rating for dust and water resistance. It also offers high insulation resistance and dielectric strength, ensuring safe and efficient operation.

Who Can Benefit from Using Our Switch?

Our switch is ideal for a wide range of applications including cars, industrial equipment, marine vessels, buses, and various electric equipment. Whether you're a manufacturer, wholesaler, or retailer, our factory direct pricing and high-quality standards make our switch a cost-effective choice.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

16A
Max. Voltage

250V
Place of Origin

Shanghai, China
Brand Name

Yong Xing
Model Number

KCD2-23N-30A
Application

Cars, Industrial, MARINE, BUSES, electric equipment, off-road vehicles
Material

plastic
Pins

4P
Whether the smart

NO
Mechanical Life

100000 times
IP level

IP40
Product name

Rocker Switch KCD2
Color

Red Yellow Green Blue White
LED Voltage

12V.24V.220V.2V.6V.110V
Contact Resistance

≤50mΩ
Dielectric Strength

1500V AC,1min
Operating temperature

T55,T85,T125
Panel cutout

30*22mm
Certification

CQC,CE,UL.ENEC
