Description
This limit switch features a contact resistance of ≤50mΩ, insulation resistance of ≥100MΩ, and dielectric strength of 1500V, ensuring safe and efficient operation. It has an electrical life of 50,000 cycles and comes with certifications including CQC, CE, ENEC, and ROHS, guaranteeing its quality and compliance with international standards.
What sets our limit switch apart is its IP40 protection level, providing excellent dust resistance. Additionally, its compact design and easy installation make it a preferred choice for many industries. Whether you’re looking for a single unit or bulk orders, we’re your go-to supplier for this essential component.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(shangkai) yongxing
|
|
Model Number
|
KW15-11A-OAA-BBA
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250VAC
|
|
Operating Temperature
|
-25℃~+125℃
|
|
Protection Level
|
IP40
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Electrical Life
|
50,000
|
|
Max. Current & Voltage
|
16A 250VAC T125 5E4 ; 10A 250V T125 5E4
|
|
Certification
|
CQC CE ENEC
|
Key Features and Advantages
Our 16A Normally Open Limit Switch stands out with its high current and voltage ratings, making it ideal for demanding applications. Its dust-resistant design and long electrical life ensure reliable performance over time.
Wide Range of Applications
From gaming consoles to water dispensers and coffee machines, this limit switch is versatile and can be integrated into various devices. Its compact size and easy installation make it a favorite among manufacturers.
Factory-Direct Pricing and Quality
As a factory supplier, we offer competitive wholesale pricing without compromising on quality. Our limit switches come with multiple certifications, ensuring they meet the highest standards of safety and performance.
