Description
| Max.Rating Current & Voltage(Resistive Load) | 3A/250V AC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ |
| Dielectric Strength | 1500V |
| Electronic Life(cycles) | 50000 |
| Mechanical Life(cycles) | 200000 |
| Operating temperature | -5°c~+75°c |
| IP code | IP40 |
Why Choose Our 16mm 2NO 2NC Momentary Push Button Switch?
Our 16mm 2NO 2NC Momentary Push Button Switch stands out due to its compact design, high electrical and mechanical life, and versatile switch combinations. As a factory-direct supplier, we offer competitive wholesale prices without sacrificing quality, making it an ideal choice for industrial controls, electronic devices, home appliances, and automotive applications.
What Are the Key Features of This Switch?
Key features include a 3A/250V AC rating, 16mm panel cutout, 2NO 2NC switch combinations, LED indicator options, and an IP40 protection level. It also boasts a long electrical life of 50,000 cycles and a high mechanical life of 200,000 cycles, ensuring reliable performance over time.
How Does Our Switch Compare to Others on the Market?
Our switch offers superior quality and value compared to similar products on the market. As a factory-direct supplier, we eliminate the middleman, allowing us to offer competitive pricing. Additionally, our switch meets CQC and CE certifications, guaranteeing its safety and compliance with international standards.
