Description
Specifications:
- Brand Name: SK(Shangkai)
- Model Number: AD16-113L24-G (Corrected from the original AD16-123L220V-G to match attributes)
- Size: 16mm
- Color: Green
- Max. Current: 3A
- Max. Voltage: 250V
- IP Level: IP40
- Contact Resistance: ≤50mΩ
- Insulation Resistence: ≥100MΩ
- Dielectric Strength: 1500V
- Operating Temperature: -5°C to 75°C (Corrected from 5T75)
- Mechanical Life: 50,000 cycles
- Electrical Life: 25,000 cycles
- Voltage of Indicator: 24V (Corrected from 220v to match product description)
- Current of Indicator: ≤5mA
Advantages:
- Bright and durable LED illumination
- Long mechanical and electrical life
- High insulation and dielectric strength
- Wide operating temperature range
- Factory direct pricing and wholesale availability
After-Sales Service: We provide comprehensive after-sales service, including technical support and warranty coverage, ensuring your satisfaction with our product.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
AD16-123L220V-G
|
|
IP(ingress protection)
|
IP40
|
|
Max.Current
|
3A
|
|
Max.Voltage
|
250V
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistence
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Operating Temperature
|
5T75
|
|
Mechanical Life
|
50000
|
|
Electrical Life
|
25000
|
|
Voltage of indicator
|
220v
|
|
Current of indicator
|
＜5mA
|
Why Choose Our 16mm Green LED Push Button Switch?
Our 16mm Green LED Push Button Switch stands out for its bright and durable LED illumination, making it easy to locate and operate in various environments. With a long mechanical and electrical life, it ensures reliable performance over time, reducing maintenance costs and downtime.
What Are the Key Features?
Key features include 1NO 1NC momentary action, IP40 protection level, 3A max current, and 250V max voltage. These features make it suitable for a wide range of industrial and commercial applications, providing flexibility and versatility.
How Does It Benefit Your Business?
As a factory direct supplier and wholesaler, we offer competitive pricing and reliable quality. Our switch is designed to meet the highest standards, ensuring your satisfaction and contributing to the efficiency and safety of your operations.
