Description
Specifications:
- Place of Origin: Shanghai, China
- Brand Name: SK (Shangkai)
- Model Number: AD16-221-W
- IP Level: IP40
- Max. Current: 3A
- Max. Voltage: 250V
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Strength: 1500V
- Operating Temperature: -5°C to 75°C
- Mechanical Life: 200,000 cycles
- Electrical Life: 50,000 cycles
- Voltage of Indicator: 24V
- Certification: CQC, CE, ROHS
Advantages:
- Durable plastic construction ensures longevity.
- LED illumination enhances visibility in low-light conditions.
- High mechanical and electrical life for reliable performance.
- Competitive pricing for wholesale purchases.
After-Sales Service: We offer comprehensive after-sales support, including technical assistance and warranty services. As a factory supplier, we ensure timely delivery and competitive pricing for bulk orders.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
AD16-221-W
|
|
IP(ingress protection)
|
IP40
|
|
Max.Current
|
3A
|
|
Max.Voltage
|
250V
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistence
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Operating Temperature
|
5T75
|
|
Mechanical Life
|
200000
|
|
Electrical Life
|
50000
|
Why Choose Our 16mm LED Push Button Switch?
Our 16mm LED Push Button Switch stands out due to its durable plastic construction, ensuring longevity and reliability. The illuminated LED feature enhances visibility in low-light conditions, making it ideal for various applications. With a high mechanical and electrical life, this switch offers consistent performance over time.
What Are the Key Specifications?
Key specifications include a 1NO1NC contact configuration, IP40 protection level, 3A max current, and 250V max voltage. It also boasts a contact resistance of ≤50mΩ, insulation resistance of ≥100MΩ, and a dielectric strength of 1500V. The operating temperature range is -5°C to 75°C, ensuring versatility in different environments.
How Does Our Wholesale Service Benefit You?
As a factory supplier, we offer competitive pricing for wholesale purchases. This means you can enjoy significant savings when buying in bulk. Additionally, our comprehensive after-sales support, including technical assistance and warranty services, ensures a hassle-free experience.
