Description
Introducing our high-quality 16mm Momentary Push Button Switch, a versatile electrical component designed for a wide range of applications. As a factory direct supplier, we offer wholesale pricing on this reliable and durable switch. With an illuminated 12V/24V LED light, it provides clear visual indication of its status, making it ideal for use in control panels, machinery, and various electronic devices. The switch is rated for 3A at 250VAC, ensuring safe and efficient operation. Its IP40 protection level guarantees resistance to dust and limited water ingress, enhancing its longevity. With a mechanical life of 200,000 cycles and an electrical life of 50,000 cycles, this switch offers exceptional durability. The contact resistance is ≤50mΩ, and the insulation resistance is ≥100MΩ, ensuring minimal power loss and high safety standards. Additionally, it boasts a dielectric strength of 1500V and an operating temperature range of -5℃ to +75℃, making it suitable for diverse environments. Choose our push button switch for its superior performance, reliability, and competitive pricing.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
AD16-121L24-W
|
|
IP(ingress protection)
|
IP40
|
|
Max.Current
|
3A
|
|
Max.Voltage
|
250V
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistence
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Operating Temperature
|
5T75
|
|
Mechanical Life
|
200000
|
|
Electrical Life
|
50000
|
|
Voltage of indicator
|
24v
|
|
Current of indicator
|
＜15mA
|
Key Features
Our 16mm Momentary Push Button Switch stands out with its illuminated 12V/24V LED light, providing clear status indication. Rated for 3A at 250VAC, it ensures safe and efficient operation in various applications.
Durability & Reliability
With a mechanical life of 200,000 cycles and an electrical life of 50,000 cycles, this switch offers exceptional durability. Its IP40 protection level and high insulation resistance guarantee long-lasting performance.
Why Choose Us?
As a factory direct supplier, we offer wholesale pricing on this high-quality switch. Our commitment to quality and customer satisfaction makes us the preferred choice for your electrical component needs.
