Description
| Max. Rating Current& Voltage | 3A 250V AC |
| Contact Resistance | ≤50mΩ Push Button Switch |
| Insulation Resistance | ≥100MΩ Momentary Push Button Switch For Lighting |
|
Electronic Life (cycles) |
25,000-50,000 |
| Mechanical Life (cycles) | 50000-200,000 |
| Operation temperature | -5℃~+75℃ Illumianted/Lighted Button Swith |
| Dielectric Stength | 1500V |
| Certification | CQC CE |
Why Choose Our 16mm Momentary Push Button Switch with Light?
Our 16mm Momentary Push Button Switch with Light is designed for durability and reliability. With a factory-direct supplier, you get competitive wholesale prices and high-quality products. The switch features a plastic cover for protection and an LED indicator for clear visual feedback, available in multiple colors. It has a long mechanical life and is suitable for a wide range of temperatures, making it ideal for various applications.
What Are the Key Features of This Switch?
Key features include a 3A 250V AC rating, a contact resistance of ≤50mΩ, and insulation resistance of ≥100MΩ. It has an electronic life of 25,000-50,000 cycles and a mechanical life of 50,000-200,000 cycles. The switch is also CQC and CE certified, ensuring safety and compliance.
How Can This Switch Benefit Your Projects?
This switch is perfect for lighting control, electrical panels, industrial equipment, and home automation. Its compact size and reliable performance make it a versatile choice for any project. With our factory-direct pricing and high-quality products, you can ensure your projects are both cost-effective and efficient.
