Description
**Key Specifications**:
– **Place of Origin**: Shanghai, China
– **Brand Name**: Sk (Shangkai)
– **Model Number**: FD16-111L24D-R (Note: Adjusted to align with provided attributes, assuming 24V DC LED as per one attribute set)
– **Protection Level**: IP40
– **Max. Current**: 1A
– **Max. Voltage**: 250V AC
– **LED Voltage Options**: 2V, 6V, 12V, 24V, 110V, 220V (Note: Listing options for flexibility)
– **Contact Resistance**: ≤50mΩ
– **Insulation Resistance**: ≥100MΩ
– **Dielectric Strength**: 1500V
– **Operating Temperature**: 25°C to 55°C
– **Electrical Life**: 5000 cycles
– **Mechanical Life**: 10000 cycles
– **Panel Cut-out Size**: 16mm
– **Panel Thickness**: 0.5-6.0mm
**Advantages**:
– **Durable Construction**: Made from high-quality plastic, ensuring longevity.
– **Clear Indication**: Red LED indicator for easy status identification.
– **Versatile Application**: Suitable for home appliances, industrial controls, and more.
– **Competitive Pricing**: As a factory supplier, we offer unbeatable wholesale prices.
– **Reliable Performance**: High electrical and mechanical life ensure consistent operation.
**After-sales Service**:
We provide comprehensive after-sales service, including technical support and warranty coverage, ensuring your satisfaction with our product.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(Shangkai)
|
|
Model Number
|
FD16-111L24D-R
|
|
Protection Level
|
IP40
|
|
Max. Current
|
1A
|
|
Max. Voltage
|
250V AC
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistence
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Operating Temperature
|
25T55
|
|
Electrical Life
|
5000
|
|
Mechanical Life
|
10000
|
|
Panel cut-out size
|
16mm
|
|
Panel thickness
|
0.5-6.0mm
|
|
LED Voltage
|
24V DC
|
|
Cap color
|
Red
|
Why Choose Our 16mm Red LED Push Button Switch?
Our 16mm Red LED Push Button Switch stands out for its durability, clear indication, and versatile application. Whether you're looking for a switch for home appliances or industrial controls, this switch is up to the task. The vibrant red LED indicator makes it easy to identify its status, while the durable plastic construction ensures longevity.
What Makes Our Switch Different?
Unlike other switches on the market, our switch offers a combination of high-quality materials, reliable performance, and competitive pricing. As a factory supplier, we cut out the middleman, offering you wholesale prices without compromising on quality. Additionally, our switch comes with a comprehensive after-sales service, ensuring your satisfaction.
How Can I Use This Switch in My Projects?
This switch is perfect for a variety of applications, including home appliances, industrial controls, electronic devices, and custom projects. Its self-locking feature and clear LED indication make it a versatile choice for any project that requires a reliable and easy-to-use switch.
