Description
**Specifications**:
– **Model Number**: LA133-A1.TD-K10 DC 24 R
– **Place of Origin**: Shanghai, China
– **Brand Name**: Sk(shangkai) yongxing
– **Protection Level**: IP40, IP65, IP67
– **Max. Current**: 10A
– **Max. Voltage**: 660 VAC
– **Rated Insulation Voltage**: 660V AC
– **Max. Insulation Voltage**: 2500 V/min
– **Usage Category**: AC-15, DC-13
– **Mechanical Life**: 1,000,000 cycles
– **Operation Frequency**: 1200 cycles/h
– **Electrical Life for AC-15**: 600,000 cycles
– **Electrical Life for DC-13**: 250,000 cycles
– **Mounting Hole Size**: 22mm Diameter
– **Lamp Voltage Options**: 6V, 12V, 24V, 36V, 48V, 110V, 220V, 380V
**Advantages**:
– **Durable Design**: With a mechanical life of 1,000,000 cycles, our switch ensures long-lasting performance.
– **High Protection Level**: IP40, IP65, and IP67 ratings make it suitable for various environments.
– **Versatile Lamp Voltage**: Supports multiple lamp voltages, meeting diverse application needs.
– **Factory Direct**: As a factory, we offer competitive wholesale prices and ensure product quality.
**Applications**:
– Industrial machinery
– Control panels
– Automation systems
– Electrical equipment
**After-Sales Service**:
We provide comprehensive after-sales service, including technical support and warranty coverage, to ensure your satisfaction.
Choose our 22mm push button switch for reliable performance and cost-effective solutions.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-A1.TD-K10 DC 24 R
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
|
Lamp Voltage
|
6v 12v 24v 36v 48v 110v 220v 380v
|
Why Choose Our 22mm Push Button Switch?
Our 22mm push button switch stands out for its durability, high protection level, and versatile lamp voltage options. With a mechanical life of 1,000,000 cycles, it ensures long-lasting performance in various industrial applications.
What Are the Key Features?
Key features include IP40, IP65, and IP67 protection levels, 10A max current, 660VAC max voltage, and support for multiple lamp voltages. These features make it suitable for a wide range of environments and applications.
How Does It Benefit Your Business?
As a factory direct supplier, we offer competitive wholesale prices, ensuring cost-effective solutions for your business. Our high-quality switches and comprehensive after-sales service provide peace of mind and reliability.
