Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD11-13T-CA1H-B-B-120
|
|
Current Rating
|
10A (single load:5A)
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CQC CE ROHS
|
|
Circuit
|
SPTT
|
|
Dimension Code
|
A1
|
|
Contact Piece Code
|
H
|
Key Features
Our SPTT 3-Way Rocker Switch stands out with its high current rating of 10A (single load: 5A) and a voltage rating of 250V AC, making it suitable for a wide range of electrical applications. The switch offers a long mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring reliable performance over time.
Differentiators
What sets our switch apart is its low contact resistance (≤50mΩ) and high insulation resistance (≥1000MΩ), which contribute to excellent electrical performance. Additionally, it is certified with CQC, CE, and ROHS, guaranteeing its quality and safety. Available in multiple colors, it's easy to find the right fit for your project.
Why Choose Us
As a factory supplier, we offer competitive wholesale prices and excellent customer service. Our SPTT 3-Way Rocker Switch is manufactured to the highest standards, ensuring you get a product that meets your needs and exceeds your expectations. Choose us for your next project and experience the difference in quality and performance.
