Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-FB1B-B-B-01
|
|
Current Rating
|
6A/10A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
B1 (21.4x15x15.2 , 19.3×13.2×12.9)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Actuator Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Switch Function
|
On Off Waterproof IP65
|
Key Features
Our 21x15mm Waterproof Rocker Switch stands out with its robust design, offering a 6A/10A current rating and 250V AC voltage capacity. Its IP65 waterproof rating ensures durability in harsh environments, making it perfect for outdoor and marine applications. With a mechanical life of 50,000 cycles and electronic life of 10,000 cycles, it guarantees long-lasting reliability.
Why Choose Us?
As a factory-direct supplier, we offer competitive wholesale pricing on our Waterproof Rocker Switch. Our product is certified with multiple international safety standards, including CQC, CE, UL, CB, ENEC17, and ROHS, ensuring quality and compliance. Choose us for reliable service and high-quality products.
Versatile Applications
This switch is ideal for a wide range of applications, including outdoor lighting, marine equipment, and industrial machinery. Its variety of color options allows for easy integration into any design. Upgrade your projects with our durable and reliable Waterproof Rocker Switch today.
