Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-E1.X2S-K11
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
Why Choose Our Rotary Push Button Switch?
Our rotary push button switch stands out for its durability, reliability, and versatility. With a max current of 10A and a max voltage of 660 VAC, it's suitable for a wide range of industrial control applications. The IP40, IP65, and IP67 protection levels ensure it can withstand harsh environments, making it ideal for outdoor or dusty settings. The mechanical life of 1,000,000 cycles and electrical life of 600,000 cycles for AC-15 and 250,000 cycles for DC-13 guarantee long-lasting performance, reducing the need for frequent replacements.
What Are the Key Features of This Switch?
This switch features a 22mm diameter mounting hole size, making it compatible with standard panel cutouts. The round head design and pin terminal provide easy installation and secure connection. Additionally, the dot illuminated option offers clear visual indication, enhancing safety and efficiency in operation. As a factory supplier, we ensure strict quality control and competitive pricing, making it a cost-effective choice for your industrial control needs.
Can I Get Bulk Discounts on This Switch?
Yes, as a factory supplier, we offer bulk order discounts on our rotary push button switches. Whether you're a distributor, reseller, or end-user, we can provide competitive pricing based on your order quantity. Contact us today to discuss your requirements and get a personalized quote. With our high-quality products and excellent customer service, you can trust us to meet your industrial control needs efficiently and affordably.
