Description
Specifications:
– Place of Origin: Shanghai, China
– Brand Name: Sk(shangkai) Yongxing
– Model Number: LA133-A1.TD-K10 DC 12 R
– Protection Level: IP40, IP65, IP67
– Max. Current: 10A
– Max. Voltage: 660 VAC
– Rated Insulation Voltage: 660v AC
– Rated Thermal Current: 10A
– Max. Insulation Voltage: 2500 V/min
– Usage Category: AC-15, DC-13
– Mechanical Life: 1,000,000 cycles
– Operation Frequency: 1200 cycles/h
– Electrical Life for AC-15: 600,000 cycles
– Electrical Life for DC-13: 250,000 cycles
– Mounting Hole Size: 22mm Diameter
– Lamp Voltage Options: 6v, 12v, 24v, 36v, 48v, 110v, 220v, 380v
Advantages:
– Durable construction with high-quality materials.
– Long mechanical and electrical life for reliable performance.
– Multiple protection levels for various environments.
– Wide range of lamp voltage options to suit different applications.
After-Sales Service:
– We provide comprehensive after-sales support, including technical assistance and warranty services.
Choose us as your trusted supplier for wholesale purchases of this high-quality push button switch.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-A1.TD-K10 DC 12 R
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
|
Lamp Voltage
|
6v 12v 24v 36v 48v 110v 220v 380v
|
Why Choose Our 22mm LED Push Button Switch?
Our 22mm LED Push Button Switch stands out due to its high-quality materials, durable construction, and long mechanical and electrical life. It's perfect for a wide range of applications, from electrical controls to industrial machinery.
Key Features and Benefits
With multiple protection levels (IP40, IP65, IP67) and a wide range of lamp voltage options, our switch is designed to perform reliably in various environments. Its momentary latching and LED-lighted features make it user-friendly and visually appealing.
Why Buy from Us?
As a direct factory supplier and wholesaler, we offer competitive prices without compromising on quality. Our comprehensive after-sales support ensures that you're always covered, making us the ideal choice for your push button switch needs.
