22mm Pushbutton Switch 10A – Wholesale from Factory Supplier

500 - 1,999  pieces
$4.50

2,000 - 4,999  pieces
$4.30

>= 5,000  pieces
$4.10

0 reviews

22mm Pushbutton Switch 10A – Wholesale from Factory Supplier

Description

Introducing our high-quality 22mm Pushbutton Switch with a 10A rating, perfect for industrial appliances. As a factory supplier, we offer wholesale prices and customization options to meet your specific needs. Our switch features a robust plastic construction, round head design, and plug terminal for easy installation. With a max voltage of 660V AC, IP40/IP65/IP67 protection levels, and a mechanical life of 300,000 cycles, it’s built to last. Our factory is equipped with advanced experimental equipment and staffed by over 60 senior engineers, ensuring top-notch quality. We adhere to 5S and 5m management standards in all workshops. Choose us for reliable, factory-direct switches that stand out from the competition.

Electronic component image for cross-border e-commerceElectronic device image for e-commerce optimizationElectronic product image for SEO optimization


Why Choose Our 22mm Pushbutton Switch?

Our 22mm Pushbutton Switch stands out with its durable plastic construction, high current rating (10A), and advanced protection levels (IP40/IP65/IP67). Designed for industrial use, it ensures reliable performance in demanding environments.

What Makes Us a Trusted Supplier?

As a factory supplier, we offer competitive wholesale prices and customization options. Our factory is equipped with state-of-the-art equipment and staffed by experienced engineers, ensuring top-quality products that meet your specifications.

How Does Our Switch Benefit Your Business?

With a long mechanical life (300,000 cycles) and high vibration resistance, our switch reduces maintenance costs and downtime. Choose us for a reliable, cost-effective solution that enhances your industrial operations.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Max. Current

10A

Max. Voltage

660V AC

Place of Origin

Shanghai, China

Brand Name

Yongxing

Model Number

LA133

LED

Other

Application

Electric, Industrial Control

Material

plastic

Structure

Electronic

Head Type

Round Head

Terminal Type

Plug Terminal

Whether the smart

NO

illuminated Type

full illuminated

IP level

IP40, ip65, ip67

Switch Combination

1NO

Operating temperature

-25℃~+55℃

mechanical life

300000

operation frequency

120 cycle/h

rated insulation voltage

AC660V

max.insulation voltage

2500V/min

vibration

10~2000Hz.1mm.15g

installation height

≤2000m

relative humidity

≤98%

Name

22mm key electrical switch lock

Protection Level

IP40/IP65/IP67
