Description
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ 4 pin push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm |
| Dielectric Strength | 2000VAC |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC emergency push button switch |
| Contact Configuration | 1NO |
| Operating Type | Momentary elevator push button switch |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our 22mm Waterproof Push Button Switch?
Our 22mm Waterproof Push Button Switch stands out in the market due to its superior quality, durability, and customization options. With an IP67 rating, it offers excellent waterproof performance, making it ideal for use in harsh environments. The switch's stainless steel, nickel-plated brass, or gold-plated brass crust provides exceptional corrosion resistance, ensuring long-lasting use. Additionally, our factory-direct pricing and wholesale availability make it a cost-effective choice for your projects.
What Are the Key Features of Our Switch?
Our switch boasts a compact 22mm size, a 2A/36VDC rating, and low contact resistance for efficient operation. It has a mechanical life of over 1,000,000 times and an electrical life of over 200,000 times, ensuring reliable performance over time. The switch also features customizable options to meet your specific needs, making it a versatile choice for various applications.
How Can Our Switch Benefit Your Business?
By choosing our 22mm Waterproof Push Button Switch, you can enhance the reliability and durability of your equipment, reducing maintenance costs and downtime. Our factory-direct pricing and wholesale availability make it easy for you to stock up on this essential component, ensuring you always have what you need on hand. Additionally, our customization options allow you to tailor the switch to your specific requirements, further optimizing its performance in your applications.
