Description
Our switch features a domed front shape and is available with a red lamp indicator, making it easy to identify and operate. It boasts a contact resistance of ≤50mΩ and an insulation resistance of ≥1000MΩ, ensuring reliable performance. With a mechanical life of over 1,000,000 times and an electrical life of over 200,000 times, this switch is built to last.
The switch is equipped with a stainless steel, nickel-plated brass, or gold-plated brass crust, and a silver alloy contact, offering excellent durability and conductivity. The button and case are made of stainless steel with a mirror surface and CD pattern, adding a touch of elegance.
Our switch is suitable for a wide range of applications, including emergency stop buttons, control panels, and more. With its momentary elevator push button switch operating type and 1NO contact configuration, it provides flexibility and convenience.
As a factory direct supplier, we offer competitive pricing and excellent customer service. We also provide customization options to meet your specific needs. Choose our 22mm Waterproof Stainless Steel Push Button Switch for a reliable, durable, and stylish solution.
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ 4 pin push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm |
| Dielectric Strength | 2000VAC |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC emergency push button switch |
| Contact Configuration | 1NO |
| Operating Type | Momentary elevator push button switch |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our 22mm Waterproof Stainless Steel Push Button Switch?
Our switch stands out with its IP67 waterproof rating, ensuring reliable operation in wet or dusty environments. The stainless steel construction and silver alloy contact provide excellent durability and conductivity, making it ideal for industrial and commercial use.
What Are the Key Features of Our Switch?
Our switch features a domed front shape, red lamp indicator, and momentary elevator push button switch operating type. It has a long mechanical and electrical life, ensuring reliable performance over time. Additionally, we offer customization options to meet your specific needs.
How Does Our Switch Compare to Others on the Market?
Our switch offers superior quality and durability at a competitive price. As a factory direct supplier, we eliminate the middleman, passing the savings on to you. Plus, our excellent customer service ensures a smooth purchasing experience.
