Description
Product Specifications:
- Model Number: AD111
- Place of Origin: Shanghai, China
- Power Frequency Withstand Voltage: 2.5KV per minute
- Insulation Resistance: ≥2MΩ
- Continuous Operating Life: ≥30,000H
- Brightness: ≥100cd/m²
- CTI: ≥100
- Protection Grade: IP65 (IP67 available on request)
- Ambient Temperature: -25℃~+55℃
- Relative Air Humidity: ≤98%
- Vibration Frequency: 2-80Hz with acceleration of 0.7g
- Pollution Degree: 3
- Installation Group: Ⅱ
- Certifications: CCC, CE, RoHS
Product Advantages:
- High brightness and long lifespan ensure reliable performance.
- IP65/IP67 protection grade makes it suitable for harsh environments.
- Customizable to meet your specific requirements.
- Factory direct pricing and wholesale availability.
After-Sales Service: We provide comprehensive after-sales service, including technical support and warranty coverage. Contact us for more details.
Why Choose Us?
- We are a factory supplier with independent production facilities.
- We have 60 senior engineers and a perfect development process.
- All workshops are up to 5S and 5M management standards.
- We offer competitive pricing and flexible MOQ.
| Power frequency with stand voltage | 2.5KV per minite |
| Insulation resistance | ≥2MΩ |
| Allowable voltage fluctuation | ±20% |
| Continous operating | ≥30000H |
| Brightness | ≥100cd/m² |
| CTI | ≥100 |
| Protective degree of the head | IP65,IP67 is available on request |
| Applying frequeny | AC50~60Hz |
| Ambient temperature | -25℃~+55℃ |
| Relative air humidity | ≤98% |
| Normally workable when vibration frequency | 2-80Hz with acceleration of 0.7g |
| Pollution degree | 3 |
| Inatallation group | Ⅲ |
| Remarks | One with “TH” mark can work in the conditioan of moist heat |
Why Choose Our 22mm LED Signal Light?
Our 22mm LED Signal Light is designed for reliability and durability, making it perfect for industrial applications. With high brightness and a long lifespan, it ensures clear signaling even in harsh environments.
Customizable to Meet Your Needs
As a factory supplier, we can customize the LED Signal Light to meet your specific requirements. Whether it's a different color, size, or functionality, we've got you covered.
Factory Direct Pricing and Wholesale Availability
By purchasing directly from the factory, you can enjoy competitive pricing and flexible minimum order quantities. Contact us today to learn more about our wholesale options.
