Description
Our switch boasts impressive specifications, including a mechanical life of 50,000 cycles and an electrical life of 10,000 cycles, ensuring long-lasting performance. It features a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, and dielectric strength of 1500V, guaranteeing safety and reliability.
Operating within a temperature range of -25℃ to +85℃ and with an IP40 protection level, this switch is suitable for various environments. Its compact size and 1NO1NC switch combination make it versatile and easy to integrate into your projects.
Choose our Yongxing KA6 Push Button Switch for its durability, performance, and competitive pricing. As a trusted supplier, we offer excellent after-sales service and support, ensuring your satisfaction with every purchase.
|
contact resistance
|
≤50MΩ
|
mechanical life（cycles）
|
50000
|
|
insulation resistance
|
≥100MΩ
|
electronic life（cycles）
|
10000
|
|
dielectric strength
|
1500V
|
operating temperature
|
25T85
|
|
IP code
|
IP40
|
max.rating current & voltage
|
3A 250V AC
|
Why Choose Our Push Button Switch?
Our Yongxing KA6 Push Button Switch stands out for its durability, high performance, and competitive pricing. With a max rating of 3A at 250V AC, it's suitable for a wide range of electrical applications. The switch's long mechanical and electrical life ensure reliable operation over time, reducing maintenance costs and downtime.
Key Features and Benefits
The switch features a compact 14mm size, making it easy to install in tight spaces. Its 1NO1NC switch combination offers flexibility in circuit design. With an IP40 protection level, it's resistant to dust and moisture, ensuring reliable performance in various environments. Additionally, our factory-direct pricing means you get high-quality products at the best possible price.
After-Sales Service and Support
As a trusted supplier, we're committed to providing excellent after-sales service and support. Our team is available to answer any questions you may have and assist with any issues that arise. Choose our Yongxing KA6 Push Button Switch for peace of mind and reliable performance.
