Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CA1H-W-S-01
|
|
Max. Current
|
4A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
EB ENEC17 ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
A1 (21.7x15x15.8 , 19.1x13x13)
|
|
Contact Piece Code
|
H (7.5 length, 2.2×0.6 welding type)
|
|
Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Function
|
On Off
|
Why Choose Our 4A 250VAC Blue Rocker Switch?
Our 4A 250VAC Blue Rocker Switch stands out for its durability, reliability, and versatility. With a mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, it ensures long-lasting performance even under heavy use. The SPST circuit provides simple and effective on/off control, making it ideal for a wide range of applications.
What Are the Key Features of This Rocker Switch?
Key features include a maximum current of 4A and a maximum voltage of 250V AC, ensuring it can handle demanding electrical loads. It also meets the CB ENEC17 and ROHS standards, guaranteeing safety and compliance. Available in multiple colors, it offers flexibility in design to suit your specific needs.
Why Buy from Us as a Factory Supplier?
As a factory direct supplier and wholesaler, we offer competitive pricing and reliable quality. We have strict quality control measures in place to ensure that every switch meets our high standards. Additionally, our excellent customer service team is always ready to assist you with any questions or concerns you may have.
