6.5A 250VAC Rotary Selector Switch | Wholesale Supplier Factory

10 - 99  pieces
$0.50

>= 100  pieces
$0.30

0 reviews

Wholesale 6.5A 250VAC Rotary Selector Switch from Factory Supplier.

Description

Our high-quality 6.5A 250VAC Rotary Selector Switch, produced by Shanghai Yongxing, is a top-tier choice for air conditioners and other electrical applications. As a factory direct supplier, we offer competitive wholesale prices. This switch boasts a single pole (SP) configuration, a sleek black finish, and is designed to withstand operating temperatures up to T150. With a maximum rating of 6.5A/250V AC or 13A/125V AC, it ensures reliable performance. Key specifications include a contact resistance of ≤50mΩ, insulation resistance of ≥100MΩ, and a dielectric resistance of 1500V AC. Its mechanical life is rated at 100,000 cycles, and the electronic life at 10,000 cycles, ensuring longevity and durability. Our switch stands out with its precision engineering, high-quality materials, and rigorous quality control, making it a superior choice over competitors. We offer excellent after-sales service and support, ensuring customer satisfaction. Choose us for your wholesale needs and experience the difference in quality and service.
Contact Resistance:
≤50mΩ
Insulation resistance:
≥100MΩ
Dielectric Resistance:
1500V AC
Operating temperature:
T125
Cetification
CQC ENEC

Electronic component product image for cross-border e-commerceElectronic device product image for e-commerce optimizationElectronic gadget product image for SEO improvementElectronic product image for cross-border e-commerce SEO


Why Choose Our Rotary Selector Switch?

Our Rotary Selector Switch is engineered for reliability and durability, making it ideal for air conditioners and various electrical applications. With a maximum rating of 6.5A/250V AC, it ensures stable performance under demanding conditions.

What Makes Our Switch Stand Out?

Our switch features a sleek black design, single pole configuration, and is built to withstand high operating temperatures up to T150. It offers a long mechanical life of 100,000 cycles and a high dielectric resistance of 1500V AC, ensuring safety and longevity.

Why Buy from Us?

As a factory direct supplier, we offer competitive wholesale prices and excellent after-sales service. Our switches are made with high-quality materials and undergo rigorous quality control, ensuring superior performance and customer satisfaction.

Push Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch CustomizedPush Button Switch Customized

Additional information

Whether the smart

NO

Max. Current

6A

Max. Voltage

250V AC

Place of Origin

Shanghai, China

Brand Name

Shanghai Yongxing

Model Number

RS3

Mechanical Life

100,000

Color

Black

Poles

SP (single pole)

Max. Rating Current&Voltage

6.5A/250V AC , 13A/125V AC

Operating temperature

T150

dielectric resistance

1500V

Contact Resistance

≤50mΩ

Insulation resistance

≥100mΩ

Electronic life

10,000cycles
