Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11N-FB1B-B-G-01-12D
|
|
Current Rating
|
10(3)A
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
B1 (21.4x15x15.2 , 19.3×13.2×12.9)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Lamp voltage
|
6V/12V/24V/110V/220V/others
|
|
Switch Function
|
On Off Illuminated Waterproof IP65
|
Key Features and Benefits
Our 6A-10A SPST Waterproof Illuminated Rocker Switch stands out with its waterproof (IP65) and illuminated design, making it ideal for outdoor and marine applications. It offers a high mechanical life of 50,000 cycles, ensuring durability and reliability. The switch is also certified with CB, ENEC17, and ROHS, guaranteeing safety and compliance with international standards.
Why Choose Our Switch?
As a factory direct supplier, we offer competitive wholesale pricing without compromising on quality. Our switch is designed to handle demanding electrical environments, with a maximum current rating of 6A/10A and a voltage rating of 250V AC. The illuminated feature provides clear visibility in low-light conditions, enhancing usability.
Applications and Flexibility
This switch is perfect for boat lighting, panel control, and various general lighting applications. It supports multiple lamp voltages (6V/12V/24V/110V/220V/others), offering flexibility for different setups. Choose our switch for its superior performance, reliability, and competitive pricing.
