Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CB1B-B-G-01
|
|
Current Rating
|
10R(3)
|
|
Voltage Rating
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
UL ROHS
|
|
Circuit
|
SPST
|
|
Dimension Code
|
B1 ( 21.4x15x15.2 , 19.3×13.2×12.9)
|
|
Contact Piece Code
|
B (8 length, 4.8×0.8 standard)
|
|
Actuator Color
|
Red,Yellow,Green,Black,Blue,Orange,White,Gray
|
|
Switch Function
|
On Off
|
Why Choose Our Mini Rocker Switch?
Our Mini Rocker Switch stands out for its high-quality construction, reliable performance, and compliance with international safety standards. With a 50,000-cycle mechanical life and a contact resistance of ≤50mΩ, it ensures long-lasting durability and efficient operation. The switch is also available in multiple colors, making it versatile for various applications.
What Are the Key Features?
Key features include a 6A 250V AC rating, SPST circuit, and On-Off function. It is CE and UL certified, ensuring safety and compliance. The switch also offers excellent insulation resistance (≥1000MΩ) and dielectric strength (1500VAC for 1 minute), making it a reliable choice for electrical controls.
Where Can It Be Used?
This switch is ideal for a wide range of applications, including home appliances, industrial equipment, automotive controls, and more. Its compact size and versatile design make it suitable for various electrical projects where a reliable and durable switch is needed.
