Description
AD16 16mm 3-Pin 1NO 1NC Multi-Color LED Push Button Switch
As a leading factory supplier, we offer high-quality AD16 16mm LED push button switches, ideal for various industrial and commercial applications. Our switches come with a 3-pin configuration, 1NO 1NC contact arrangement, and vibrant multi-color LED indicators, making them both functional and visually appealing.
Product Specifications
- Max. Rating Current & Voltage: 3A 250V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥100MΩ
- Dielectric Strength: 1,500V
- Electronic Life: Momentary: 50,000 cycles; Alternate: 25,000 cycles
- Mechanical Life: Momentary: 200,000 cycles; Alternate: 50,000 cycles
- Certification: CQC, CE
- Operating Temperature: -5℃~+75℃
- IP Code: IP40
- LED Colors: Red, Blue, Green, Yellow, White
- Indicator Voltage: 2V, 6V, 12V, 24V, 110V, 220V
- Panel Cutout: 16mm
- Action: Self-locking, Momentary
Product Advantages
Our switches are designed with durability and reliability in mind. With a team of 60 senior engineers, an injection molding workshop, and an independent plant, we ensure top-notch quality and customization options. Whether you need a specific color, voltage, or action type, we can tailor the switch to meet your requirements.
After-Sales Service
We stand behind our products with excellent after-sales service. If you encounter any issues, our dedicated support team is here to assist you promptly.
Wholesale & Customization
As a factory supplier, we offer competitive wholesale prices and flexible customization options. Contact us today to discuss your needs and get a quote.
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC indicator light |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ 220 volt led indicator lights |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 |
Why Choose Our AD16 LED Push Button Switch?
Our AD16 LED push button switch stands out with its vibrant multi-color LED indicators, durable construction, and flexible customization options. Whether you need a specific color to match your equipment or a custom voltage to suit your application, we've got you covered.
What Are the Key Features?
Key features include a 3-pin configuration, 1NO 1NC contact arrangement, and a wide range of LED colors. The switch also offers excellent electrical performance, with a max. rating current of 3A and a max. rating voltage of 250V AC.
How Can We Help with Customization?
As a factory supplier, we offer flexible customization options. Whether you need a specific color, voltage, or action type, our team of engineers can work with you to create a switch that meets your exact requirements. Contact us today to discuss your customization needs.
