Description
Our LED Signal Indicator Light stands out with its exceptional brightness (≥100cd/m²) and long continuous operating life (≥30,000H). It features a high protective degree (IP65, IP67 available on request) and is suitable for a wide range of frequencies (AC 50-60Hz or customized). The insulation resistance is ≥2MΩ, and it can withstand a power frequency voltage of 2.5KV per minute (effective AV value).
This indicator light is built to withstand harsh environments, with an ambient temperature range of -25℃ to +55℃ and a relative air humidity of ≤98%. Its pollution degree is 3, and it operates normally under vibration frequencies of 2-80 Hz with an acceleration of 0.7g. Available in yellow and other colors upon request, this LED light is a versatile choice for industrial applications.
As a factory-direct supplier, we ensure the highest quality standards and offer customization options to meet your specific needs. Choose our LED Signal Indicator Light for reliable performance and cost-effective solutions.
|
item
|
value
|
|
|
Place of Origin
|
Shanghai,China
|
|
|
Brand Name
|
SK(Shangkai)
|
|
|
Model Number
|
AD111-22A-DC.AC 24V R
|
|
|
LED voltage
|
ac dc 24v
|
|
|
Protective degree of the head
|
IP65, IP67 is available on request
|
|
|
Applying frequency
|
AC 50-60Hz or customized
|
|
|
Brightness
|
≥100cd/m2
|
|
|
Continous operating life
|
≥30000H
|
|
|
Insulation resistance
|
≥2MΩ
|
|
|
Power frequency withstand voltage
|
2.5KV per min (effective AV value)
|
|
|
CTI
|
≥100
|
|
|
Ambient temperature
|
-25℃~+55℃
|
|
|
Relative air humidity
|
≤98%
|
|
|
Pollution degree is 3,inatallation group is Ⅲ. Normally workable when vibration frequency is 2-80 Hz with acceleration of 0.7g
|
||
Why Choose Our 22mm LED Signal Indicator Light?
Our 22mm LED Signal Indicator Light is designed for industrial use, offering high brightness and long life. With an IP65/IP67 protective degree, it's suitable for harsh environments. The AC/DC 24V compatibility makes it versatile for various applications.
What Makes Our Product Stand Out?
As a factory-direct supplier, we ensure quality and cost-effectiveness. Our LED light has a brightness of ≥100cd/m² and a continuous operating life of ≥30,000H. It also features high insulation resistance and can withstand power frequency voltages.
Where Can Our LED Signal Indicator Light Be Used?
Our product is ideal for industrial equipment, panel mounting, control systems, machinery indicators, and factory automation. Its vibration resistance and wide temperature range make it suitable for various industrial settings.
