Description
What sets our micro switch apart is its exceptional performance and durability. It boasts a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, dielectric strength of 1500V, and an impressive electrical life of 50,000 cycles. The SPDT 3PIN function and black color add to its versatility and aesthetic appeal.
As a factory supplier, we offer wholesale pricing and customization options to meet your specific requirements. Our independent plant, injection molding workshop, and advanced experimental equipment, combined with a team of over 60 senior engineers and 5S management in all workshops, ensure top-notch quality and efficient production.
Choose us for your micro switch needs and experience the difference of factory-direct pricing, superior quality, and exceptional customer service. Contact us today to discuss your bulk order or customization needs!
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100mΩ |
| Dielectric Strength | 1,500V |
| Electronic Life | 50,000 cycles |
| Operating temperature | -25℃~+125℃ |
| Rating current&voltage | 5A/250VAC |
Why Choose Our 5A 250V Mini Micro Switch?
Our mini micro switch stands out for its high quality, durability, and versatility. With a maximum current of 5A and a maximum voltage of 250V, it's suitable for a wide range of electrical applications. The wide operating temperature range from -25℃ to +125℃ ensures reliability in extreme conditions.
What Are the Key Features of Our Micro Switch?
Key features include a contact resistance of ≤50mΩ, insulation resistance of ≥100mΩ, dielectric strength of 1500V, and an electrical life of 50,000 cycles. The SPDT 3PIN function and IP41/IP65 protection level add to its appeal.
How Can We Help You with Customization?
As a factory supplier, we offer customization options to meet your specific requirements. Whether you need a different color, size, or functionality, our team of senior engineers can work with you to create the perfect micro switch for your application.
