Description
Key Specifications:
- Place of Origin: Shanghai, China
- Brand Name: Sk(shangkai) Yongxing
- Model Number: LA133-A1.MD-K11 24V G
- Protection Level: IP40, IP65, IP67
- Max. Current: 10A
- Max. Voltage: 660 VAC
- Rated Insulation Voltage: 660V AC
- Mechanical Life: 1,000,000 cycles
- Electrical Life: 600,000 cycles (AC-15), 250,000 cycles (DC-13)
- Mounting Hole Size: 22mm Diameter
- Lamp Voltage Options: 6V, 12V, 24V, 36V, 48V, 110V, 220V, 380V
Product Advantages:
- Customizable: Tailor the switch to your specific needs with various voltage and LED options.
- Durable: High mechanical and electrical life ensures long-lasting performance.
- Versatile: Suitable for a wide range of applications, from machinery control to lighting systems.
- Factory Direct: As a factory supplier, we offer competitive pricing and direct support.
After-Sales Service: We provide comprehensive after-sales service, including technical support and warranty coverage, ensuring your satisfaction with our product.
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-A1.MD-K11 24V G
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
|
Lamp Voltage
|
6v 12v 24v 36v 48v 110v 220v 380v
|
Why Choose Our 30mm Push Button Switch?
Our 30mm push button switch stands out with its customizable options, high durability, and versatile applications. Whether you need a switch for industrial control, machinery operation, or lighting systems, our product offers reliable performance and long-lasting service.
What Makes Our Switch Unique?
Unlike many competitors, our switch is customizable to meet your specific voltage and LED requirements. Additionally, its high mechanical and electrical life ensures that it can withstand frequent use without failing, making it a cost-effective choice for your business.
How Can We Help You?
As a factory supplier and wholesaler, we offer competitive pricing and bulk order discounts. Our team is also available to provide technical support and answer any questions you may have about our product. Choose us for a reliable, high-quality push button switch that meets your needs and exceeds your expectations.
