10mm 3 Pin Latching Push Button Switch – Factory Direct Wholesale Supplier
Introducing our high-quality 10mm 3 Pin Latching Push Button Switch, available directly from our factory at wholesale prices. As a leading supplier, we offer competitive pricing without compromising on quality. Our switch is designed with precision, featuring a 1NO1NC switch combination, self-locking operation type, and a bright yellow color for easy visibility.
Product Specifications:
- Max. Current: 3A
- Max. Voltage: 250V AC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥1000 MΩ
- Dielectric Strength: 1500V
- Electric Life: 25,000 cycles
- Mechanical Life: 50,000 cycles
- Operating Temperature: -5°C to +75°C
- IP Code: IP40
- Mounting Hole Size: 10mm
- LED Indicator: Yes
Product Advantages:
Our switch stands out from the competition with its durable construction, reliable performance, and competitive pricing. As a factory-direct supplier, we have full control over the manufacturing process, ensuring consistent quality and timely delivery. We also offer customization services for bulk orders, allowing you to tailor the switch to your specific needs.
After-Sales Service:
We stand behind our products with a comprehensive after-sales service. If you encounter any issues or have questions about our switch, our dedicated customer support team is ready to assist you.
Why Choose Us?
- Factory-direct pricing for cost savings
- High-quality materials and construction
- Customization options for bulk orders
- Reliable after-sales service
| Max.Rating Current & Voltage(Resistive Load) | 3A/250V AC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ |
| Dielectric Strength | 1500V |
| Electronic Life(cycles) | 25000 |
| Mechanical Life(cycles) | 50000 |
| Operating temperature | -5°c~+75°c |
| IP code | IP40 |
Why Choose Our 10mm 3 Pin Latching Push Button Switch?
Our 10mm 3 Pin Latching Push Button Switch is designed for durability and reliability, making it an ideal choice for industrial control, home appliances, and electronic devices. With its self-locking operation type and 1NO1NC switch combination, it provides stable and consistent performance.
What Are the Key Features of Our Switch?
Key features include a 10mm mounting hole size, 3A/250V AC rating, IP40 protection level, and an LED indicator for easy status monitoring. These features ensure our switch meets the demands of various applications.
How Can We Benefit From Your Factory-Direct Pricing?
As a factory-direct supplier, we offer competitive pricing without compromising on quality. This means you can enjoy cost savings while still receiving a high-quality product. Additionally, we offer customization options for bulk orders, allowing you to tailor the switch to your specific needs.
