Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11N-CB1B-B-R-01
|
|
Max. Current
|
6A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST 2 Pin On Off Rocker Switch
|
|
Dimension Code
|
B1, 19.5x13mm mounting hole size
|
|
Contact Piece Code
|
B, 4.8×0.8x8mm
|
|
Lamp voltage
|
No lamp
|
|
Function
|
On-Off SPST rocker switch
|
Why Choose Our Rocker Switch?
Our rocker switch is designed with durability and reliability in mind, offering a long mechanical life of 50,000 cycles and an electronic life of 10,000 cycles. With a maximum current of 6A and a maximum voltage of 250V AC, it's suitable for a wide range of applications, from electrical appliances to industrial controls.
What Makes Our Switch Stand Out?
Our switch features low contact resistance (≤50mΩ) and high insulation resistance (≥1000MΩ), ensuring safe and reliable operation. It also meets stringent safety standards with certifications including CQC, CE, UL, CB, ENEC17, and ROHS. As a factory direct supplier, we offer competitive wholesale prices and excellent after-sales service.
How Can Our Switch Benefit Your Business?
By choosing our rocker switch, you're not only getting a high-quality product but also the assurance of dealing directly with a factory supplier. This means better pricing, faster delivery, and the ability to customize your order to meet specific needs. Our switch is perfect for enhancing the functionality and reliability of your products, giving you an edge in the market.
