Description
|
item
|
value
|
|
Certification
|
CE RoHS
|
|
Whether the smart
|
Yes
|
|
Place of Origin
|
China
|
|
Brand Name
|
Shanghai Yongxing
|
|
Model Number
|
YXDGQ16F-10Z/J/S
|
|
Protection Level
|
IP65
|
|
Max. Current
|
3A
|
|
Max. Voltage
|
250V
|
|
LED
|
Other
|
|
Electronic Life
|
10000 cycles
|
|
Mechanical Life
|
50000 cycles
|
|
Working Environment Temperature
|
-25℃~+65℃
|
|
Switch circuit
|
1NO
|
|
Electrical Resistance
|
AC250V, 1min, no flicker and breakdown
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥100MΩ
|
Why Choose Our 16mm Push Button Switch?
Our 16mm push button switch is designed for durability and reliability, making it ideal for industrial control applications. The brass construction ensures longevity, while the IP65 protection level allows it to withstand harsh environments. With a high insulation resistance and low contact resistance, it provides excellent electrical performance, ensuring your devices operate smoothly.
What Are the Key Features of Our Switch?
Our switch features latching functionality, a waterproof design, and a wide operating temperature range. It can handle a maximum current of 3A and a maximum voltage of 250V, making it suitable for demanding electrical loads. Additionally, it has a long electronic and mechanical life, ensuring reliability over time.
How Can We Help You as a Supplier?
As a factory direct supplier, we offer competitive wholesale prices and ensure top-notch quality. We provide excellent customer service and support, helping you find the right push button switch for your needs. Choose us for reliable, high-quality products and exceptional service.
