Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
SK(Shangkai)
|
|
Model Number
|
AY16-111-2
|
|
Protection Level
|
IP40
|
|
Max. Current
|
3A
|
|
Max. Voltage
|
250V AC
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistence
|
≥100MΩ
|
|
Dielectric Strength
|
1500V
|
|
Operating Temperature
|
25T55
|
|
Electrical Life
|
25000
|
|
Mechanical Life
|
50000
|
|
Panel cut out
|
16mm
|
|
Panel thickness
|
0.5-6.0mm
|
|
Position
|
2 Positions,1NO+1NC
|
Why Choose Our 16mm Rotary Key Switch?
Our 16mm Rotary Key Switch is designed for industrial control applications, offering a reliable and durable solution for equipment selection and power control. With its 16mm panel cut-out and 0.5-6.0mm panel thickness compatibility, it fits a wide range of industrial panels. The switch's 180° rotation range and latched mechanism provide flexibility and ease of use.
What Makes Our Switch Stand Out?
Our switch stands out with its high-quality plastic construction and pin terminal type, ensuring durability and easy installation. It also boasts an IP40 protection level, low contact resistance, and high insulation resistance, making it safe and reliable in demanding industrial environments. Additionally, our factory direct wholesale pricing and excellent after-sales service make us the preferred choice for industrial control components.
What Are the Key Specifications of Our Switch?
Our switch has a maximum current of 3A and a maximum voltage of 250V AC, with a dielectric strength of 1500V. It has an operating temperature range of 25°C to 55°C, and electrical and mechanical lives of 25000 and 50000 cycles respectively. These specifications ensure that our switch can handle the rigors of industrial use, providing long-lasting performance and reliability.
