Description
|
item
|
value
|
|
Place of Origin
|
Shanghai,China
|
|
Brand Name
|
Sk(shangkai) yongxing
|
|
Model Number
|
LA133-A1.P-H11
|
|
Protection Level
|
IP40 IP65 IP67
|
|
Max. Current
|
10A
|
|
Max. Voltage
|
660 VAC
|
|
Rated Insulation Voltage
|
660v ac
|
|
Rated Thermal Current
|
10A
|
|
Max.insulation voltage
|
2500 V/min
|
|
Usage Category
|
AC-15 DC-13
|
|
Mechanical Life
|
1000,000
|
|
Operation frequency
|
1200 cycles/h
|
|
Electrical life for AC-15
|
600000 cycles
|
|
Electrical life for DC-13
|
250000 cycles
|
|
Mounting Hole Size
|
22mm Diameter
|
Why Choose Our Push Button Switch?
Our push button switch is designed with durability and performance in mind. With a customizable logo option, you can brand your products effortlessly. The switch's high current and voltage ratings make it suitable for a wide range of industrial applications, ensuring reliable operation even under demanding conditions.
What Makes Our Switch Stand Out?
Our switch offers a long mechanical life and high operation frequency, reducing the need for frequent replacements. The protection levels of IP40, IP65, and IP67 ensure that the switch remains functional even in dusty or wet environments. Additionally, our factory-direct pricing and wholesale options make it a cost-effective choice for bulk purchases.
What After-Sales Service Do We Offer?
We pride ourselves on providing excellent after-sales service. If you encounter any issues with your purchase, our dedicated support team is here to assist you. We also offer a warranty on our products, giving you peace of mind with every purchase. Choose us for your push button switch needs and experience the difference in quality and service.
