Description
Product Specifications:
- Size: 22mm
- Material: Stainless Steel with a mirror surface and CD pattern
- LED: Yes, enhancing visibility and functionality
- IP Level: IP67, ensuring excellent waterproof performance
- Switch Rating: 2A / 36VDC
- Contact Resistance: ≤50mΩ
- Insulation Resistance: ≥1000MΩ
- Dielectric Strength: 2000VAC
- Mechanical Life: >1,000,000 times
- Electrical Life: >200,000 times
- Operating Temperature: -20℃~+55℃
Product Advantages:
- High Durability: Constructed with high-quality stainless steel, ensuring long-lasting performance.
- Waterproof Design: IP67 rating provides reliable protection against water ingress, making it suitable for outdoor and wet environments.
- LED Illumination: Integrated LED enhances visibility, especially in low-light conditions.
- Versatile Applications: Ideal for elevators, control panels, industrial machinery, and more.
Why Choose Us:
- Factory Direct: As a direct supplier, we offer competitive prices and ensure product quality.
- Customization Options: We can tailor the switch to your specific needs, including different materials and configurations.
- Reliable After-Sales Service: Our dedicated team is always ready to assist with any inquiries or issues.
Whether you’re looking to buy in bulk or need a single unit, we’re your go-to supplier for high-quality elevator push button switches.
| Panel Thickness | 1-10mm |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥1000 MΩ 4 pin push button switch |
| Torque | 5-14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Mounting Hole Size | 22mm |
| Dielectric Strength | 2000VAC |
| Electronic Life | >1,000,000 times |
| Mechanical Life | >200,000 times |
| Operating temperature | -20°c~+55°c |
| IP code | IP67 IK09 |
| Switch Rating | 2A /36VAC emergency push button switch |
| Contact Configuration | 1NO |
| Operating Type | Momentary elevator push button switch |
| The Front Shape | High Round |
| The Crust Material | Stainless Stell,Nickel-plated Brass or Gold-Plated Brass |
|
Material |
Contact : Sliver Alloy (Can be made to order) |
Why Choose Our Elevator Push Button Switch?
Our elevator push button switch stands out due to its high-quality stainless steel construction, ensuring durability and longevity. The integrated LED enhances visibility, making it ideal for use in low-light conditions. Additionally, its IP67 waterproof rating provides reliable protection against water ingress, making it suitable for outdoor and wet environments.
What Are the Key Features of This Switch?
Key features include a 22mm size, 2A/36VDC rating, ≤50mΩ contact resistance, and ≥1000MΩ insulation resistance. It also offers a mechanical life of over 1,000,000 times and an electrical life of over 200,000 times, ensuring reliable performance over time.
Can We Customize the Switch to Our Needs?
Yes, as a factory supplier, we offer customization options to meet your specific requirements. Whether you need a different material, configuration, or size, we can tailor the switch to your needs.
