Description
Key Specifications:
– Max. Rating Current: 3A
– Max. Rating Voltage: 250V AC
– Contact Resistance: ≤50mΩ
– Insulation Resistance: ≥100mΩ
– Dielectric Strength: 1,500V
– Electronic Life: 50,000 cycles (Momentary), 25,000 cycles (Alternate)
– Mechanical Life: 200,000 cycles (Momentary), 50,000 cycles (Alternate)
– IP Code: IP40
– Operating Temperature: -5℃ to +75℃
Our switch stands out with its durable construction, advanced experimental equipment for quality control, and the ability to customize according to your requirements. With over 60 senior engineers and 5S management in all workshops, we ensure top-notch products and services. Choose us for your wholesale needs and experience the difference in quality and service.
| Max. Rating Current & Voltage (Resistive Load) |
3A 250V AC |
| Contact Resistance | ≤50mΩ |
| Insulation Resistance | ≥100MΩ |
| Dielectric Resistance | 1,500V |
| Electronic life(cycles) | Momentary:50,000 Alternate:25,000 |
| Mechanical life(cycles) | Momentary:200,000 Alternate:50,000 |
| Certification |
CQC , CE |
| Operating temperature | -5℃~+75℃ |
| IP code | IP40 push button illuminated switch |
Why Choose Our 12mm Illuminated Push Button Switch?
Our 12mm illuminated push button switch offers superior performance and durability, making it ideal for a wide range of industrial and commercial applications. With a double pole double throw mechanism and bright LED indicator, it provides reliable operation and clear visual feedback.
What Are the Key Advantages of Our Switch?
Our switch stands out with its advanced quality control, customizable options, and competitive pricing. As a direct factory supplier, we can meet your bulk order needs efficiently and cost-effectively.
What Are the Applications of Our Switch?
Our switch is suitable for use in various industrial and commercial settings, including control panels, machinery, and automation systems. Its illuminated design and multiple color options make it versatile and easy to integrate into different environments.
