Description
|
item
|
value
|
|
Place of Origin
|
Shanghai, China
|
|
Brand Name
|
SK(shangkai) Yongxing
|
|
Model Number
|
KCD3-11-CB1B-B-R-01/UL-transparent button
|
|
Max. Current
|
6A
|
|
Max. Voltage
|
250V AC
|
|
Mechanical Life
|
50000 Cycles
|
|
Contact Resistance
|
≤50mΩ
|
|
Insulation Resistance
|
≥1000MΩ
|
|
Dielectric Strength
|
1500VAC 1 Minute
|
|
Electronic Life (cycles)
|
10,000
|
|
Certificate
|
CB ENEC17 ROHS
|
|
Circuit
|
SPST 2 Pin On Off Rocker Switch
|
|
Dimension Code
|
B1, 19.5x13mm mounting hole size
|
|
Contact Piece Code
|
B, 4.8×0.8x8mm
|
|
Lamp voltage
|
No lamp
|
|
Function
|
On-Off SPST rocker switch
|
Why Choose Our SPST 2 Pin Rocker Switch?
Our SPST 2 Pin Rocker Switch is a top choice for electrical projects due to its high-quality construction and reliable performance. With a maximum current of 6A and a maximum voltage of 250VAC, it can handle a wide range of electrical loads. The UL certification ensures its safety and compliance with international standards, giving you peace of mind.
What Are the Key Features of Our Rocker Switch?
Our rocker switch features a long mechanical life of 50,000 cycles and an electronic life of 10,000 cycles, ensuring durability and longevity. The low contact resistance (≤50mΩ) and high insulation resistance (≥1000MΩ) provide excellent electrical performance. Additionally, the dielectric strength of 1500VAC for 1 minute ensures the switch can withstand high voltage without breaking down.
How Does Our Factory Direct Supply Benefit You?
As a factory direct supplier and wholesaler, we offer competitive prices without compromising on quality. You can enjoy significant cost savings by purchasing directly from us. Our reliable supply chain ensures timely delivery, and our dedicated customer service team is always ready to assist you with any inquiries or issues.
