Description
contact resistance
|
≤50MΩ
|
electronic life(cycles)
|
10000
|
insulation resistance
|
≥100MΩ
|
operating temperature
|
5T55
|
dielectric strength
|
1500V
|
IP code
|
IP40
|
Why Choose Our 10mm Black Momentary Push Button Switch?
Our 10mm Black Momentary Push Button Switch stands out for its compact size, reliable performance, and durability. The momentary operation allows for quick and efficient control, making it ideal for temporary needs. With a factory-direct wholesale approach, we offer competitive prices without compromising on quality.
What Are the Key Features of This Switch?
This switch features a SPST 1NO configuration, a maximum current of 1A, and a maximum voltage of 250V AC. It has an electronic life of 10,000 cycles, ensuring long-lasting reliability. The black plastic casing provides both aesthetics and protection, while the CQC, CE, and ROHS certifications guarantee safety and compliance.
Where Can This Switch Be Used?
Our 10mm Black Momentary Push Button Switch is versatile and can be used in various electrical devices, industrial applications, and home appliances. Its compact size and reliable performance make it a popular choice for temporary control needs.
