Factory Direct Wholesale 10mm SP-ST Push Button Switch | Electric Appliances Supplier

Name: Factory Direct Wholesale 10mm SP-ST Push Button Switch | Electric Appliances Supplier
SKU: 68288
Availability: InStock

Category: KA series Tags: Electric Appliances, Factory Wholesale, Push Button Switch

>= 100 pieces
$0.28

Rated 0 out of 5

0 reviews

Factory Direct Wholesale SP-ST Push Button Switch | Electric Appliances Supplier | Durable & Reliable

Description
Specification

Description

Introducing our high-quality SP-ST Push Button Switch, a factory-direct wholesale product designed specifically for electric appliances. As a leading supplier, we offer this switch in a variety of colors including Red, White, Green, Yellow, Black, Blue, Gray, and Orange, ensuring it meets the diverse needs of our customers. With a compact 10mm size and 12mm mounting hole, this switch is perfect for tight spaces. It boasts a maximum current of 1A and a maximum voltage of 250V AC, making it suitable for a wide range of applications. Our switch features a round head design and pin terminals for easy installation. It has an electronic life of 10,000 cycles, ensuring long-lasting durability. The contact resistance is ≤50mΩ, and the insulation resistance is ≥100mΩ, providing reliable performance. It operates within a temperature range of -5℃ to +55℃ and has a dielectric strength of 1500V, with an IP40 rating for dust and water resistance. This switch is ideal for electric, home appliance, and industrial control applications. Choose our factory-direct wholesale switch for quality, reliability, and cost-effectiveness.

contact resistance	≤50MΩ	electronic life（cycles）	10000
insulation resistance	≥100MΩ	operating temperature	-5℃ to +55℃
dielectric strength	1500V	IP code	IP40

Why Choose Our SP-ST Push Button Switch?

Our SP-ST Push Button Switch stands out for its quality, durability, and versatility. As a factory-direct wholesale supplier, we offer competitive pricing without compromising on quality. The switch's 10mm size and 12mm mounting hole make it ideal for compact spaces, while its high current and voltage ratings ensure reliable performance in various applications.

Key Features and Benefits

With an electronic life of 10,000 cycles, our switch is built to last. Its low contact resistance and high insulation resistance provide reliable electrical connections. The switch operates within a wide temperature range and has a high dielectric strength, ensuring safety and reliability. Additionally, its IP40 rating offers protection against dust and water, making it suitable for industrial environments.

Applications and Compatibility

Our SP-ST Push Button Switch is perfect for electric appliances, home appliances, and industrial control systems. Its round head design and pin terminals make installation quick and easy. Choose from a variety of colors to match your application's aesthetic needs. Trust our factory-direct wholesale switch for your next project.

Additional information

Max. Current	1A
Max. Voltage	250V AC
Place of Origin	Shanghai, China
Brand Name	Yong Xing
Model Number	KA1A-12
LED	NO
Application	Electric, Home Appliance, Industrial Control
Material	plastic
Structure	Electronic, Mechanical, Electromagnetic
Head Type	Round Head
Terminal Type	Pin terminal
Whether the smart	NO
illuminated Type	none
IP level	IP40
Switch Combination	1NO1NC, 1NO
Electronic life(cycles)	10,000
Color	Red, Yellow ,Green, Black, White, Blue, Gray, Orange
Operation Type	Alternate,Moment
material	plastic+mental
Contact Resistance	≤50mΩ
Insulation Resistance	≥100mΩ
IP code	IP40
Operating temperature	-5℃~+55℃
Dielectronic Strength	1500V
